Q1. Name the three popular construction types of positive displacement pump?

Ans. The three popular construction type of a positive displacement pump are 1. Gear 2. Vane and 3. Piston.

Q2. how is the volumetric efficiency of a positive displacement pump determined?

Ans. Equation for calculating volumetric efficiency is given below

Volumetric efficiency = flow @ 10 psi/ flow at 0 psi.

Q3.  Name the important consideration when selecting a pump for a particular application?

Ans. A pump transfers fluid from one point to another point by converting the mechanical energy produced by the impeller into pressure energy.  As pressure is the key thing for any kind of pump so it is necessary for a user to consider the fluid property, they are going to transfer, environmental condition, operating speed, flow rate requirement and working period when it comes to select the pump for an application.

Q4. How is pressure developed in a hydraulic system?

Ans. We can develop pressure in a hydraulic system by altering the cross sectional area or we can also develop pressure by changing the distance between the motor and pump. As we all know that pressure is directly proportional to the force applied and inversely to the cross sectional area. So if we alter the cross sectional area we can alter the pressure.

Q5. Why should the suction head of a pump not exceed 5 psi?

Ans. Different pump design has different inlet pressure. This inlet pressure can be reduced by reducing the incoming water supply pressure (if necessary). Excessive inlet pressure can cause wear and tear of the inlet manifold seal. To prevent the flow thorough, the suction head pressure must be lesser than the backpressure by 5 psi unit. However the back pressure must not exceed the rate discharge pressure.

Q6. What is the theoretical flow rate from a fixed displacement axial piston pump with a nine bore cylinder operating at 2000 rpm? Each bore has a 0.5- in diameter and the stoke is 0.75- in.

Ans.

Given,

Diameter (D) = 0.5 in

Stroke length (S) = 0.75- in

Speed (N) = 2000 rpm

Bore (Y) = 9.

We know that for a fixed displacement axial piston pump theoretical flow rate

Qth = A*D*N*Y*tan(o)/231

Qth = (.196)*(.5)*(2000)*(9)*(1.5)/231                                  { tan(o)= S/D => tan(o) = .75/.5}

Qth = 11.47 gpm.
